Computer control over the entire process. From film roll to final bag, one process flow. Servo motor, makes it easy to adjust the bag length and the production speed. Automatic film feeding, coordination free from tension adjustment.
Features:
1. Automatically stop when film feeding blocks or bags jam.
2. High production efficiency to save manpower and time.
3. Equipment with heat sealing and cold cutting device.
Main Technical Parameter
|
Model |
SHXJ-D1000 |
SHXJ-D1200 |
SHXJ-D1500 |
|
Cutting&Sealing Width |
920mm |
1120mm |
1420mm |
|
Maximum Bag Length |
2000mm |
2000mm |
2000mm |
|
Machine Speed |
40-100pc/min ×6 |
40-100pc/min×6 |
40-100pc/min×6 |
|
Number of Strip |
6 |
6 |
6 |
|
Power of Motor |
2.2kw |
3kw |
4kw |
|
Weight (kg) |
1300kgs |
1300kgs |
1600kgs |
|
Dimension |
4500×2000×1800mm |
4600×2100×1800mm |
4800×2200×1800mm |
|
Bag Material |
LDPE,HDPE,LLDPE,recycle film |
||
|
Kind of Bag |
T-shirt bag,Shopping bag,super market bag,KFC bag,Carrefour bag,LuLu Bag |
||
|
Bag Color |
Transparent,Black,Red,White,blue bag,color changed by masterbatch |
||
|
Power Voltage |
220V |
||
|
Machine Working Time |
24 hours * 7 days |
||
|
Warranty |
1 year |
||
※Correct specifications depend on the actual model. All specifications are subject to change without prior notice.
If you only buy one machine,we will pack machine with wooden pack,and loading container with Less Than Container Load（LCL）.
Our Main parts cooperator as following brand,but standard parts all made from China.
Kingdom Machine Co., Ltd. information column provides you with a film blowing machine, plastic bag machine, plastic recycling machine, flexo printing machine, stretch film machine, and bubble film machine information, including meaning, working principle, application fields, price, and other news.
This article tells you about the characteristics, application range, and maintenance methods of the film blowing machine so that you can understand it better and use it better.
The film blowing machine is used to blow HDPE and LDPE films, which are used in various high-end film packaging, plastic bag films, etc. This kind of film can be widely used in light and heavy packaging due to its good barrier properties, preservation, moisture-proof, frost-proof, oxygen-proof, and oil-resistant.
How to Build Up A Plastic T-shirt Bag Machine? Want Kind Of Machine Need To Buy?
Plastic films can be seen everywhere in our lives, but how did plastic films come from? We have to mention the blown film machine at this time.
