Economic Rotogravure Printing Machine
 Economic Rotogravure Printing Machine
 Economic Rotogravure Printing Machine

Economic Rotogravure Printing Machine

It’s suitable for BOPP, PET, PVC, PE and combined film and paper with the same properties, it’s printing speed is 50m/min.



Type

ASY-A600

ASY-A800

ASY-A1000

Printing Width

600mm

800mm

1000mm

Printing Length

240-850mm

240-850mm

240-850mm

Max.Printing Speed

50m/min

50m/min

50m/min

Format Precision

±0.25mm

±0.25mm

±0.25mm

Main motor

4kw

4kw

4kw

Fan Power

0.19kw/group

0.19kw/group

0.19kw/group

Heating Power

3.2kw

3.2kw

3.2kw

Overall Dimension

8800×1200×1700mm

8800×1400×1700mm

8800×1600×1700mm



Economic Rotogravure Printing Machine

Economic Rotogravure Printing Machine

Economic Rotogravure Printing Machine



Economic Rotogravure Printing Machine

Economic Rotogravure Printing Machine

Economic Rotogravure Printing Machine
