Four Colors Flexographic Printing Machine

This machine is suitable for printing such packing materials as polyethylene, polyethylene plastic bag, glass paper and roll paper etc. And it is a kind of ideal printing equipment for producing paper packing bag for food, supermarket handbag, vest bag and clothes bag, etc.

Material:

LDPE film,HDPE film,BOPP film,Paper,PET film,hot shrink film

Four Colors Flexographic Printing Machine

Performance:

Easy operation,flexible starting,accurate color register.

the meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.

Pneumatic printing cylinder lift and lower, is will stir the printing ink automatically after lifting .

the printing ink is spread by the anilox cylinder with even ink color.

Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.

360°continuous and adjustable longitudinal register device.

The frequency control of motor speed adapts to different printing speeds.

There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.

Model of Machine	YT-4600	YT-4800	YT-41000
Color	Four color	Four color	Four color
Max.Width of Printing Material	600mm	800mm	1000mm
Max.Printing Width	560mm	760mm	960mm
Length Range of Printed Product	191-914mm	191-914mm	191-914mm
Max.Diameter of Roll Material	450mm	450mm	450mm
Printing Speed	5-50m/min	5-50m/min	5-50m/min
Thickness of plate(Including Two-sides Glue Paper)	2.38mm	2.38mm	2.38mm
Total Power	11kw	13kw	15kw
Weight of Machine	3000kg	3500kg	4000kg
Overall Dimensions(m)	420016002400mm	420018002400mm	420020002400mm
