Two Colors Flexographic Printing Machine

Flexographic printing machine adopt sensitization resin as flexible printing plate, It is suitable for printing such packing materials as polyethylene,polypropylene bag,cellophane and roll paper, etc. It is a kind of ideal printing equipment for producing paper packing bag for good, supermarket handbag, vest bag and clothes bag, etc.

Two Colors Flexographic Printing Machine

Performance:

Easy operation,flexible starting,accurate color register.

the meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.

Pneumatic printing cylinder lift and lower, is will stir the printing ink automatically after lifting .

the printing ink is spread by the anilox cylinder with even ink color.

Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.

360°continuous and adjustable longitudinal register device.

The frequency control of motor speed adapts to different printing speeds.

There are Jogging/Stopping buttons on the plate roller base and material rolling rack so as to make it easy operate the machine when the plate is installed.

	YT-2600	YT-2800	YT-21000
	Two color	Two color	Two color
Max.Width of Printing Material	600mm	800mm	1000mm
Max.Printing Width	560mm	760mm	960mm
Length Range of Printed	191-914mm	191-914mm	191-914mm
Max.Diameter of Roll Material	450mm	450mm	450mm
Printing Speed	5-50m/min	5-50m/min	5-50m/min
Thickness of plate(Including Two-sides Glue Paper)	2.38mm	2.38mm	2.38mm
Total Power	8Kw	10Kw	12Kw
Outline Dimension	2300×190×2200mm	2300×2100×2200mm	2300×2300×2200mm
